Data Logger & Software
The WE800 Weather Station Data Logger offers state-of-the-art technology for continuous data logging, storing and retrieving of weather station information. All weather stations include the GL500 Data Logger, Global Water Data Logger Software, and a RS232 cable (for communication between the logger and your computer).
The GL500 Data Logger, the weather station's durable and powerful data logging and recording unit, is enclosed in a sturdy weatherproof case. The weather station data logger will operate for several months before its internal 12VDC battery requires recharging. When used in conjunction with solar panels, the weather station data logger can be powered continuously. The GL500 Data Logger includes a real-time clock that dates and time stamps each record. Weather station data can be accessed easily either through a real-time data screen or through a log of recorded data (programming and calibration are not required). Maximums, minimums, and averages can also be obtained from the data using most spreadsheet programs. All weather station data collected by the weather station data recorder can easily be transferred to a disk file for future analysis and storage. The weather station data can be imported into any standard spreadsheet program.
What is included?
GL500-7-2 Multi-Channel Data Logger
GL450 Environmental Enclosure W/ Rechargeable Battery
WE550 Wind Speed Sensor
WE570 Wind Direction Sensor
WE700 Temperature Sensor
WE600 Humidity Sensor
WE770 Solar Shield
WE820 1 inch 304 stainless steel mounting frame with 316 stainless steel fittings, 6 ft tall, 3 ft wide crossbar
Features
• Fully integrated, easy-to-use, and economical
• High quality, rugged, industrial grade sensors for monitoring, alarming, and reporting
• Powerful and durable datalogging
• Operates for several months on internal, rechargeable battery or continuously with solar panel additions
• Global Water's Windows-based datalogging software provides many useful features, such as real time monitoring, measurement interval and engineering unit selections, station ID, and sensor calibration
• Wind Direction, Wind Speed, Humidity, and Temperature Sensor electronics are fully encapsulated in marine grade epoxy for complete environmental protection and a long operating life
Optional Sensors and Accessories
• WE100 Barometric Pressure Sensor
• WE300 Solar Radiation Sensor
• WE710 Flat Surface Temperature Sensor
• WL400 Water Level Sensor
• EP180 Evaporation Pan
• RG200 Rain Gauge 6", Tipping Bucket
• RG600 Rain Gauge 8", Tipping Bucket
• FN0000 Smart Charger
• SP101 Solar Panel (80mA)
• SP102 Solar Panel (350mA)
• and the WE830 Mounting Tripod
Applications
Agriculture
Education
Environmental Studies
Landfills
Reclamation
Wastewater Facilities
Water Budget Analysis
Water Conservation
GL500-7-2 Multi-Channel Data Logger
The WE800 weather stations includes this multi-channel data logger. 7 analog 4 - 20 mA channels/inputs and 2 pulse/contact closure inputs. This data logger interfaces with all 3 wires 4 - 20 mA industrial and environmental monitoring sensors.
Available with batteries and solar panels.
Remote monitoring system for your WE800 weather station.
Brand: Sommer Messtechnik
Call for pricing
SKU: 22142
MRL-8 4G Weatherproof Data Logger for Remote Environmental Monitoring
The Sommer MRL-8 Weatherproof Data Logger is designed for reliable remote monitoring in demanding environmental and industrial applications. Whether monitoring water levels, flow systems, weather conditions, or process variables, this rugged platform provides dependable data collection and remote communication for unattended sites.
At AWM Instruments, we help customers build complete monitoring solutions tailored to their specific application — from standalone field stations to fully integrated telemetry systems with cloud-based access and alarm notifications.
Features/Benefits
Data readout with USB memory stick, Bluetooth-interface or USB or RS-232
Parameterization Via RS-232, Bluetooth, USB, Ethernet
Integrated 4G modem and weatherproof
Reliable and Power Saving
Optimized for environmental monitoring in remote sites without power
External Power Options: Battery, AC to DC Power Suppliers, Solar Panels
Integrated solar charge controller (For Solar Power Configurations)
Compatible with any 4 - 20 mA, SDI-12 or RS485 Sensors
Backlit display for data visualization or configuration
RS-232, Bluetooth, USB, or Ethernet Communication (Ethernet is an optional feature)
Solid design, compact and weatherproof aluminum housing (Powder Coated)
Remote/Wireless Data Transmission (4G Modem) (Ethernet) (Satellite - INMARSAT) (Requires Data Plan)
Shipping: This product ships in approximately 4 - 6 weeks from time of order
Brand: SignalFire Telemetry
Product: Cloud-Based Cellular Data Transmitter for Remote Monitoring
The SignalFire RANGER transmitter is sensor agnostic, connects quickly and easily, and provides power to even the most remote sensor — all without the effort and cost of trenching or cabling. Paired with your existing cloud or the SignalFire Cloud, the RANGER system is the simplest way to access all of your sensor data from one platform. Whether you’re converting an existing system or building a new system, going wireless with SignalFire means you can go live and start accessing your sensor data almost immediately.
Ideal for monitoring flow, total and rate, level and pressure, weather, water quality, rainfall and so much more.
Features
LTE CAT M1 connectivity optimized for low data usage
MQTT/SparkPlugB built-in for any MQTT-ready host
Integrated inputs/output for multi-sensors
Class I Division 2 Certified for hazardous locations
Data location from built-in GPS
SignalFire cloud monitoring/alarming service
Powers sensors from the battery or external DC Power
Shipping Note: This item ships in approximately (7 - 10) business days
For complete technical specifications and available options, please refer to the RANGER datasheet.
