Seametrics PS9800 Submersible Level & Pressure Transmitter

from $1,206.00
Pressure Range + Material:
Cable Selection:

Brand: Seametrics

High-accuracy 4–20 mA level measurement with optional temperature output

The Seametrics PS9800 is a high-accuracy, submersible pressure transmitter for continuous water level and liquid pressure measurement. Its two-wire 4–20 mA output integrates directly with data loggers, PLCs, SCADA systems, process displays, and telemetry equipment.

Designed for long-term deployment in wells, tanks, surface water, wastewater, and environmental monitoring applications, the PS9800 combines ±0.1% full-scale accuracy with thermal compensation, electrical noise immunity, and built-in transient protection. Gauge and absolute pressure configurations are available, along with optional temperature measurement, titanium construction, and multiple submersible cable materials.

Key Features

  • ±0.1% full-scale pressure accuracy

  • Two-wire 4–20 mA pressure output

  • Optional temperature measurement

  • Gauge and absolute pressure configurations

  • 9–24 VDC low-power operation

  • Thermally compensated from 0–50°C

  • Built-in transient and reverse-polarity protection

  • Acetal and 316 stainless steel construction

  • Optional titanium construction

  • Polyurethane, polyethylene, or ETFE submersible cable

  • Slim 0.75-inch diameter for wells and narrow installations

  • Optional 1/4-inch NPT end-cone adapter

Shipping Note: This product ships in approximately 7 - 10 business days

Brand: Seametrics

High-accuracy 4–20 mA level measurement with optional temperature output

The Seametrics PS9800 is a high-accuracy, submersible pressure transmitter for continuous water level and liquid pressure measurement. Its two-wire 4–20 mA output integrates directly with data loggers, PLCs, SCADA systems, process displays, and telemetry equipment.

Designed for long-term deployment in wells, tanks, surface water, wastewater, and environmental monitoring applications, the PS9800 combines ±0.1% full-scale accuracy with thermal compensation, electrical noise immunity, and built-in transient protection. Gauge and absolute pressure configurations are available, along with optional temperature measurement, titanium construction, and multiple submersible cable materials.

Key Features

  • ±0.1% full-scale pressure accuracy

  • Two-wire 4–20 mA pressure output

  • Optional temperature measurement

  • Gauge and absolute pressure configurations

  • 9–24 VDC low-power operation

  • Thermally compensated from 0–50°C

  • Built-in transient and reverse-polarity protection

  • Acetal and 316 stainless steel construction

  • Optional titanium construction

  • Polyurethane, polyethylene, or ETFE submersible cable

  • Slim 0.75-inch diameter for wells and narrow installations

  • Optional 1/4-inch NPT end-cone adapter

Shipping Note: This product ships in approximately 7 - 10 business days

PS9800 Datasheet
Seametrics Catalog
Request a Quote
ORDERING GUIDE

How to Configure the Seametrics PS9800

Configure the PS9800 by selecting the pressure reference, measurement range, output, construction, cable material, and required cable length.

1

Select Gauge or Absolute Pressure

Gauge Pressure

Recommended for most continuous water-level applications. The vented cable compensates for changes in atmospheric pressure.

Absolute Pressure

Uses a sealed reference and does not require a vented cable. Barometric compensation may be required for accurate water-level calculations.

2

Select the Measurement Range

Choose a pressure range that exceeds the maximum expected water depth or operating pressure. Avoid selecting a range that is significantly higher than necessary, since a properly matched range provides better usable measurement resolution.

5 PSIG 12 ft H2O
15 PSIG 35 ft H2O
30 PSIG 69 ft H2O
50 PSIG 115 ft H2O
100 PSIG 231 ft H2O
300 PSIG 692 ft H2O

The ranges shown above are standard gauge-pressure configurations. Absolute-pressure configurations are also available.

3

Select the Measurement Output

Pressure Only

Provides a two-wire 4–20 mA output for continuous liquid-level or pressure measurement.

Pressure + Temperature

Adds an optional temperature measurement channel for applications that require both level and water-temperature data.

4

Select the Sensor Construction

Standard Construction

Acetal and 316 stainless steel construction for groundwater, surface water, tanks, and general water-level monitoring.

Optional Titanium

Select titanium when enhanced corrosion resistance is required for saltwater, brackish water, or chemically aggressive liquids.

5

Select the Cable Material

Polyurethane

A flexible, abrasion-resistant choice for most groundwater, surface-water, and general monitoring installations.

Polyethylene

Suitable when additional moisture resistance or compatibility with certain liquids is required.

ETFE

Provides enhanced chemical and temperature resistance for more demanding installations.

6

Specify the Cable Length

Select a cable length that reaches from the installed sensor to the termination point, data logger, control panel, or telemetry enclosure. Include additional length for routing, service loops, and future maintenance.

Avoid submerged cable splices. Whenever possible, use one continuous cable from the sensor to a dry and accessible termination point.

Need Help Configuring the PS9800?

AWM Instruments can help you select the appropriate pressure range, output, construction, cable material, and cable length for your application.

Get Pricing & Availability Fast
TECHNICAL DATA

PS9800 Technical Specifications

Standard specifications are shown below. Contact AWM Instruments for configuration assistance, cable selection, or special measurement ranges.

Measurement Pressure; temperature measurement available as an option
Output 4–20 mA, 2-wire
Supply Voltage 9–24 VDC; approximately 100 ms warm-up
Pressure Accuracy ±0.1% FSO, static BFSL at 20°C
Pressure Element Media-isolated silicon strain-gauge transducer; 316 stainless steel or Hastelloy
Gauge Pressure Ranges 5, 15, 30, 50, 100, and 300 psi
Gauge Level Ranges 12, 35, 69, 115, 231, and 692 ft H2O
3.5, 10.5, 21, 35, 70, and 210 m H2O
Absolute Pressure Ranges 30, 50, 100, 300, and 500 psi
Absolute Level Ranges 35, 81, 196, 658, and 1,000 ft H2O
10, 24, 59, 200, and 340 m H2O
Temperature Measurement Optional thermistor; 0–50°C (32–122°F)
Temperature Accuracy ±0.3°C typical at 25°C; ±0.75°C maximum at 25°C
Compensated Temperature Range 0–50°C (32–122°F)
Recommended Operating Temperature −5–70°C (23–158°F); freeze protection is required when operating in water below freezing
Body Materials Acetal and 316 stainless steel; optional titanium construction
Submersible Cable Options Polyurethane, polyethylene, or ETFE
Desiccant 1–3 mm indicating silica gel
Field Connector Available as an option
Maximum Operating Pressure 1.1 × full-scale range
Burst Pressure 3 × full-scale range, up to 600 psi maximum
Dimensions 8.44 in long × 0.75 in diameter (21.4 × 1.9 cm)
Weight Approximately 0.8 lb (0.4 kg)
Optional Adapter 1/4-inch NPT end-cone adapter; 300 psi maximum

Absolute sensor depth ranges account for atmospheric-pressure offset. Specifications and available configurations are subject to change.
