Submersible Water Level Transmitters to measure and monitor levels in groundwater wells, rivers, streams, tanks, lift stations and open channels tanks, reservoirs, dams and more.
Analog Water Level Transmitter
MODEL PS98i Submersible Water Level Transmitter
Seametric's’ 4-20 mA Submersible Water Level Transmitter
Accuracy ±0.25% FSO (static, B.F.S.L. 20˚C)
Measures water level
Optional Temperature Output
Designed with built-in transient protection
Includes reverse polarity protection
Analog Water Level Transmitter
MODEL PS9800 Submersible Water Level Transmitter
Seametrics’ 4-20 mA Highly Accurate Submersible Water Level Transmitter
Narrow 0.75″ diameter, 8″ length
Optional temperature Output
Industry standard, 2-wire, 4-20 mA configuration
Absolute or gauge
± 0.06% FSO typical accuracy
Operates on low power
316 stainless steel, fluoropolymer, PTFE construction (titanium option available)
Available with a variety of cable options—polyethylene, polyurethane, or FEP
1/4 NPT end cone adapter option
Digital Water Level Transmitter
MODEL PT12 Digital Submersible water level transmitter
Seametrics’ (SDI12) Digital Water Level Transmitter
Can transform your analog sensors into a digital sensor system
Easy to connect with SDI-12 recorders—convenient for an existing SDI-12 system
Features a Modbus® RTU communication interface for further flexibility
Offers great noise immunity, thermal performance, and transient protection
Water Level Logger
PT2X Water and Temperature Data Logger
The PT2X measures and records temperature and water level, vented cable for automatic barometric pressure compensation. The PT2X is also available as an absolute water level logger.
Integrated data logger collects up to 520,000 records
Thermally compensated for volatile conditions
Easily connects with other sensors via RS485 network
Includes Aqua4Plus and Aqua4Plus Lite control software
