JENCO 101C Conductivity & Temperature Electrode/Cell
JENCO 101C Conductivity & Temperature Electrode/Cell

3177MB Benchtop Meter W/ Bluetooth Connectivity

from $59.00
Part Number:

Brand: JENCO Instruments

Product Type: Benchtop Meter for Conductivity, Salinity, TDS and Temperature

Jenco’s 5th generation benchtop series consists of single and multi-parameter models, with
or without Bluetooth connectivity. The 3177B is a single parameter conductivity / salinity /
TDS / temperature Bluetooth benchtop meter that pairs with iOS and Android tablets to
enable the same user experience as users’ favorite apps while providing graphing, guided
calibration procedures, GLP-compliant data storage, data sharing, cloud data storage and
user-defined compliance policies.

The 3177MB is available as “Meter Only” or as a Meter Kit, Contact us for more information.

Brand: JENCO Instruments

Product Type: Benchtop Meter for Conductivity, Salinity, TDS and Temperature

Jenco’s 5th generation benchtop series consists of single and multi-parameter models, with
or without Bluetooth connectivity. The 3177B is a single parameter conductivity / salinity /
TDS / temperature Bluetooth benchtop meter that pairs with iOS and Android tablets to
enable the same user experience as users’ favorite apps while providing graphing, guided
calibration procedures, GLP-compliant data storage, data sharing, cloud data storage and
user-defined compliance policies.

The 3177MB is available as “Meter Only” or as a Meter Kit, Contact us for more information.


Benchtop Meter for water quality measurements in the laboratory

3177MB 8-Pin DIN Connector

Standard 8-pin DIN for conductivity and temperature electrodes

Improved Electrode Serviceability and Low Cost of Ownership

Water quality meter operating with iOS or Android Applications

iOS and Android tablet connectivity

Free iOS and Android apps are as easy and convenient to use as users’ favorite apps, and allow complete control of all on-meter functionality plus guided calibration procedures and much more.

Easily Share Data Locally or to the Cloud

Share stored data to other apps such as Notes and Evernote or to cloud services such as Google Docs.

3177MB Can be paired with your tablet or smart phone

Display conductivity, salinity or TDS with temperature readings simultaneously with last calibration date and real-time graphing.

101 - 101 C Specifications

Product Description:

101 Electrode: Epoxy/Carbon, 8-Pin Connector, K=1.0

101C Electrode: Epoxy/Carbon, 8-Pin Connector, K=0.475

Conductivity Range: 50.0 uS/cm to 200.0 mS/cm

Operating Temperature: 0 to 80 °C

Temperature Sensor: 10 K NTC

Cell Constant: K=0.475 (4 - wire)

Length: 150 mm

Diameter: 15.3 mm

Body Meterial: EPOXY

Sensor Material: Graphite

Connector: 8 pin DIN

Cable Length: 1 m

109A - 109L Specifications

Conductivity Range: 0 to 200 uS/cm

Cell Constant: K=0.1 (2 wire)

Operating Temperature: 5 to 90 °C

Temperature Sensor: 10 K NTC

Length: 155 mm

Diameter: 12 mm

Body Meterial: Glass

Sensor Material: Pt

Connector” 4 pin （109A） / 8 pin （109L）

Cable Length: 1 m
