Precise nutrient balance is vital for healthy crops, the Automatic Online Multi-Ion Nutrients Analyzer from NT Sensors measures seven key ions—calcium, chloride, sodium, potassium, ammonium, nitrate, and magnesium—in real-time, and without reagents.
It uses seven dedicated ISE (Ion-Selective Electrode) sensors to deliver accurate, drift-free readings for each ion. Subsequently, the unit runs automatic calibration, self-cleaning, and data transmission via Modbus or Webserver, so you always have live insights. Features an IP66-rated enclosure which withstands dust, spray, and temperature swings in greenhouses or field installations.
Plug-and-play analyzer reduces manual checks and prevents nutrient imbalances that stunt growth. Finally, seamless integration with SCADA/PLC systems lets you automate nutrient dosing, boost yield, and cut waste—effortlessly and continuously.
Technical Specifications
| Measured Parameters | Calcium (Ca²⁺), chloride (Cl⁻), sodium (Na⁺), potassium (K⁺), ammonium (NH₄⁺), nitrate (NO₃⁻), and magnesium (Mg²⁺) |
|---|---|
| Number of Ion Channels | Up to 7 |
| Measurement Technique | Ion-selective electrode potentiometry |
| Measurement Range | 1–10,000 mg/L |
| Measurement Resolution | 0.01 mg/L |
| Measurement Units | mg/L (ppm) |
| Automatic Functions | Calibration, measurement, and cleaning |
| Calibration | Automatic two-point calibration |
| Cleaning | Automatic cleaning cycle |
| Measurement-Cycle Time | Approximately 5 minutes |
| Sample Consumption | Approximately 60 mL per measurement cycle |
| Pump Flow Rate | 100 mL/min |
| Sample Temperature | 5–40°C (41–104°F) |
| Permissible Sample pH | pH 4–9 |
| Sample Pressure | Designed to operate at atmospheric pressure; maximum positive sample pressure is 1.5 bar (22 psi) |
| Communication | Modbus TCP/IP |
| Operating Mode | Server/slave |
| Network Connection | RJ45 Ethernet |
| Default Network Configuration | Dynamic IP address via DHCP; default port 502 |
| Power Supply | 100–240 VAC, 0.7 A, 50/60 Hz |
| Operating Temperature | 5–40°C (41–104°F) |
| Operating Humidity | 25–75% RH |
| Enclosure | IP66-rated polycarbonate enclosure |
| Dimensions |
400 × 300 × 180 mm 15.75 × 11.81 × 7.09 in. |
| Listed Product Weight | 4.7 kg (approximately 10.4 lb) |
| Product SKU | A7-30X-204 |
Measurement performance depends on the selected electrodes, sample composition, calibration standards, and operating conditions. A pressure reducer is required when the sample pressure exceeds the analyzer’s permitted inlet pressure. Specifications are subject to change.
Multi-Ion Nutrient Monitoring Applications
Simultaneous nutrient measurement helps growers, researchers, and water-management professionals identify imbalances, improve dosing, and make informed operating decisions.
Hydroponics & Aquaponics
Monitor essential ions in recirculating water to maintain nutrient balance and support consistent growing conditions.
Fertigation Systems
Track nutrient concentrations in greenhouse and open-field irrigation systems to support controlled fertilizer application.
Vertical Farming & Precision Dosing
Provide multi-ion data for automated dosing, nutrient adjustment, and recycling in controlled-environment agriculture.
Runoff & Wastewater Monitoring
Measure nutrients in agricultural runoff, process water, and wastewater to support treatment, reuse, and environmental oversight.
What is an AMIC Multi-Ion Analyzer?
A multi-ion analyzer is an advanced water quality monitoring system designed to measure multiple dissolved ions simultaneously in real time. Using ion-selective electrode (ISE) technology, these analyzers eliminate the need for time-consuming laboratory testing and provide continuous, accurate data directly from the field or process line. This makes it an ideal solution for applications requiring fast, data-driven decision-making.
What is included
Probes for Calcium (Ca) Chloride (Cl), Sodium (Na), Potassium (K), Ammonium (NH₄), Nitrate (NO₃) & Magnesium (Mg)
Ref sensor
Tubing set
2x 2L Standards included
