The AMIC Online Salinity Analyzer is configured for continuous, simultaneous measurement of sodium and chloride using ion-selective electrode (ISE) technology. By monitoring both ions in real time, the system provides a clearer understanding of changing salinity conditions in irrigation, desalination, water treatment and industrial processes.
Dedicated sodium and chloride sensors provide stable, repeatable measurements without chemical reagents. The analyzer automatically performs calibration, measurement and cleaning cycles, reducing routine maintenance and operator involvement.
Measurement data can be viewed remotely through the integrated web server or transmitted via Modbus TCP/IP for connection to PLC and SCADA systems. This allows operators to monitor changing conditions and make timely process adjustments.
The IP66-rated enclosure protects the analyzer against dust and water ingress in demanding installations. Its compact, integrated design simplifies installation and supports dependable long-term operation.
AMIC Online Salinity Analyzer Specifications
Automatic, reagent-free measurement of sodium and chloride for continuous salinity monitoring and process control.
| Measured Parameters | Sodium and chloride |
|---|---|
| Measurement Technology | Ion-selective electrode (ISE) |
| Concentration Range | 1–10,000 ppm* |
| Working pH Range | 2–9 |
| Repeatability | ±10% |
| Minimum Sampling Interval | 5 minutes |
| Sample Measurement | Direct measurement without reagents |
| Operation | Automatic sampling, calibration, measurement and cleaning |
| Calibration Mode | Direct calibration |
| pH Measurement | Available as an option |
| Communications | Modbus TCP/IP and integrated webserver |
| Network Connection | Ethernet (RJ45) |
| System Integration | Compatible with PLC and SCADA control systems |
| Environmental Protection | IP66 |
| Power Supply | 85–240 VAC / 12 VDC, 2 A |
| Dimensions | 400 × 300 × 180 mm (15.75 × 11.81 × 7.09 in.) |
| Weight | 4.7 kg (10.4 lb) |
| Included Components | Sodium and chloride probes, reference sensor, tubing set, two 2-liter standards and Ethernet communication |
| Product Series | AMIC |
| SKU | A7-30X-202 |
| GTIN | 8436610062602 |
*Measurement range depends on the operating range of the individual sodium and chloride electrodes and the sample conditions.
Salinity Analyzer Applications
Continuous sodium and chloride measurement supports salinity management, equipment protection and automated water-quality control.
Irrigation and Fertigation
Monitor sodium and chloride in irrigation water, nutrient solutions and fertigation systems to help manage salinity.
Desalination Processes
Track changing sodium and chloride concentrations to support desalination performance and process optimization.
Water Quality Monitoring
Provide continuous salinity information for brackish water, environmental studies and water-treatment operations.
Corrosion Prevention
Detect and trend chloride and sodium levels that may contribute to corrosion in piping, equipment and industrial water circuits.
Industrial Process Control
Integrate salinity measurements into PLC or SCADA systems for automated monitoring and process adjustments.
Osmolarity Process Control
Monitor sodium and chloride concentrations in processes where ionic balance and osmolarity must be consistently controlled.
Product and Process Water
Support salinity verification in food, beverage, pharmaceutical and other processes with defined water-quality requirements.
Marine and Brackish Water Research
Continuously observe sodium and chloride changes in marine, estuarine and brackish-water studies.
