200-WS-23 Current Loop Wind Sensor

from $906.00
Part Number:

Brand: NovaLynx

This product ships in 5 - 7 business days from time of order. (Order online or request a quote)

200-WS-23 measures both wind speed and direction | 200-WS-23S measures wind speed only.

The 200-WS-23 Current Loop Wind Sensor monitors wind speed and direction. The electronics converts the raw signals from the wind sensors to proportional 4 to 20 mA current loop values for use by process control or monitoring systems. It acts like a variable resistance that draws 4-20 mA when powered with 8 to 30 Vdc.

No external power is required because the encoding electronics for wind speed and for wind direction are isolated and powered from their respective 2-wire current loops.

The wind sensor includes a three cup anemometer and wind vane. The sensor is ruggedly constructed of UV resistant ABS plastic and anodized aluminum parts, and includes 40' of cable. Additional cable lengths can be supplied. The electronics package is supplied in a gasketed wall mount NEMA enclosure.

Each parameter is converted into 4-20mA output signals for use by process control or monitoring systems. No external power is required since the encoding electronics for wind speed and for wind direction are isolated and powered from their respective 2-wire current loops.

Need a data logger or display? Click here to see options.

Wind speed and direction monitoring sensors and systems are critical for environmental analysis, industrial safety, process optimization, and regulatory compliance. These measurements provide real-time data for decision-making across a wide range of industries and applications.

Brand: NovaLynx

This product ships in 5 - 7 business days from time of order. (Order online or request a quote)

200-WS-23 measures both wind speed and direction | 200-WS-23S measures wind speed only.

The 200-WS-23 Current Loop Wind Sensor monitors wind speed and direction. The electronics converts the raw signals from the wind sensors to proportional 4 to 20 mA current loop values for use by process control or monitoring systems. It acts like a variable resistance that draws 4-20 mA when powered with 8 to 30 Vdc.

No external power is required because the encoding electronics for wind speed and for wind direction are isolated and powered from their respective 2-wire current loops.

The wind sensor includes a three cup anemometer and wind vane. The sensor is ruggedly constructed of UV resistant ABS plastic and anodized aluminum parts, and includes 40' of cable. Additional cable lengths can be supplied. The electronics package is supplied in a gasketed wall mount NEMA enclosure.

Each parameter is converted into 4-20mA output signals for use by process control or monitoring systems. No external power is required since the encoding electronics for wind speed and for wind direction are isolated and powered from their respective 2-wire current loops.

Need a data logger or display? Click here to see options.

Wind speed and direction monitoring sensors and systems are critical for environmental analysis, industrial safety, process optimization, and regulatory compliance. These measurements provide real-time data for decision-making across a wide range of industries and applications.


Datasheet
Request a Sales Quote

Wind Speed & Wind Direction Monitoring

Accurate Data. Smarter Decisions. Safer Operations.

⚫ Wind Speed ➤ Wind Direction
1Industrial &
Process Control
🏭 🌬️)))
🏭

Monitor wind conditions for emissions control, process safety, ventilation optimization, and hazardous gas dispersion.

2Water & Wastewater /
Environmental Monitoring
💧 🌿 🌬️)))
💧

Track wind for odor control, pollutant dispersion, water quality protection, and environmental impact assessments.

3Aviation &
Transportation
✈️ 🛫 🌬️)))
✈️

Support safe takeoff, landing, runway operations, crosswind monitoring, and transportation safety decisions.

4Renewable Energy
🌬️ ☀️ 📡)))
⚡

Optimize turbine yaw alignment, maximize energy production, and evaluate site performance and reliability.

5Agriculture &
Precision Farming
🚜 🌱 🌬️)))
🌱

Support spraying decisions, frost protection, irrigation planning, microclimate monitoring, and wind-sensitive operations.

6Construction &
Structural Monitoring
🏗️ 🏢 🌬️)))
🏗️

Monitor wind for crane safety, worker protection, dust control, and structural load assessments during construction.

7Marine & Offshore
Operations
🚢 🌊 🌬️)))
🚢

Ensure safe vessel operations, offshore platform safety, cargo handling, navigation, and weather routing.

8Research & Advanced
Monitoring
🔬 ⛰️ 🌬️)))
🔬

Collect high-accuracy wind data for meteorological research, climate studies, forecasting models, and advanced analytics.

◎
Accurate MeasurementsReliable wind speed and direction data.
🛡️
Enhanced SafetyReduce risks and protect people and assets.
📊
Better DecisionsData-driven insights for optimal operations.
☁️
All-Weather ReliabilityBuilt for tough environments and long-term performance.

200-WS-23 Technical Specifications

Wind Speed

  • Speed threshold: 0.8 mph

  • Transducer type: Reed switch

  • Speed constant: 1.25 mph = 1 pps

  • Measurement range: 0-100 mph (standard)

    • Optional: 0-50 m/s, 0-100 knots, 0-200 km/hr

  • Accuracy: 1 mph or ± 3%

Wind Direction

  • Azimuth accuracy: ± 3°

  • Bearings: Bushing

  • Potentiometer gap: 5°

  • Threshold: 1.2 mph

  • Measurement range: 0-360°

Current Loop

  • Accuracy: ± 1% full scale

  • Output span: 4 to 20 mA, proportioned to 0-100 mph

  • Output span: 4 to 20 mA, proportioned to 0-360°

  • Supply voltage range: 8 to 30 Vdc

  • 2-wire loop interface: Screw terminal block

  • Interface power: Derived from current loop

  • Circuit time constant: 1 sec

  • Temperature range: -58° to 140° F (-50° to 60° C)

Dimensions

  • Wind speed and direction: 12 H x 10" W

  • Wind speed only: 4.5" H x 8.5" W

  • Electronics enclosure size: 4.7" H x 4.7" W x 2.25" D

  • Sensor cable length: 40'

  • Weight/Shipping: 4 lbs/6 lbs

200-WS-23 Wind Speed & Direction Sensor Specifications

Wind Speed
Speed Threshold 0.8 mph
Transducer Type Reed Switch
Speed Constant 1.25 mph = 1 pulse per second (pps)
Measurement Range 0 to 100 mph (standard)
Optional Ranges 0–50 m/s, 0–100 knots, 0–200 km/h
Accuracy ±1 mph or ±3% of reading
Wind Direction
Measurement Range 0–360°
Azimuth Accuracy ±3°
Bearings Bushing
Potentiometer Gap 5°
Starting Threshold 1.2 mph
4-20 mA Current Loop Output
Accuracy ±1% Full Scale
Wind Speed Output 4–20 mA proportional to 0–100 mph
Wind Direction Output 4–20 mA proportional to 0–360°
Supply Voltage 8–30 VDC
Interface 2-Wire Loop, Screw Terminal Block
Interface Power Derived from Current Loop
Circuit Time Constant 1 Second
Environmental
Operating Temperature -58°F to 140°F (-50°C to 60°C)
Mechanical
Wind Speed & Direction Assembly 12" H × 10" W
Wind Speed Only Assembly 4.5" H × 8.5" W
Electronics Enclosure 4.7" H × 4.7" W × 2.25" D
Sensor Cable Length 40 ft (12.2 m)
Weight & Shipping
Net Weight 4 lbs (1.8 kg)
Shipping Weight 6 lbs (2.7 kg)
